Based on experience and previous developments, Holectron engineers have created an innovative luminaire – Minia Opal / Microprism Pendant. The Minia luminaire has a compact, balanced design. The luminaire is simple and easy to assemble and install.
When developing the Minia luminaire, great attention was paid to the smallest details. New optics, lenses were specially developed for Minia.
Minia luminaire is designed for perfect illumination in offices, shopping malls, hotels, retails, restaurants, schools, factories and residentials.
Minia luminaire is designed for perfect illumination in offices, shopping malls, hotels, retails, restaurants, schools, factories and residentials.
For Minia we use highest quality 3-step MacAdam LED modules with white color range of 2700K – 4000K and a high color rendering index (CRI), which is
CRI90+ or even CR95+.
2700K-4000K white color
CRI90+ / CRI 95+
Efficacy up to 130 Lm/W
L90B10 60.000hours
Microprism or Opal
3-step MacAdam LEDs
Driver inside housing
Continuous line possibility
IP20
Fixed output, DALI or 0-10V dimmable
Various lengths in 0.28m – 3.08m range
Customization for
your project
Microprism
Microprism
Direct lighting
Direct- indirect lighting
Microprismatic cover assures low glare and homogenous light, pleasant soft light output, and modern luminaire look at the same time.
Opal
Opal
Direct lighting
Direct- indirect lighting
Opal cover assures homogeneous, wider beam angle light, perfectly suitable for continuous white line effect.
Light types: Static white, Tunable white
CCT: 2700-4000K white color range
(on demand can be in any CCT range 2000-6500K)
CRI: CRI90+, CRI95+
LED sources: flexible LED strips for direct and indirect light
Lighting types: Static white, Tunable white
CCT: Wide 1800K-6500K white color range
CRI: CRI90+, CRI95+
Direct
Direct / Indirect
Minia luminaire is suitable for creating lighting systems in offices, shopping malls, hotels, retails, restaurants, schools, factories.
Minia luminaires housings come in standard white, black or gray colors. However, this Minia luminaire can be customized to any RAL color and almost any length.
Black
White
Gray
Custom color on request
The shape and proportions of the Minia luminaire correspond to the golden section. Therefore, the luminaire easily fits into any geometry of the room.
Length from 0.28m up to 3.08m
Minia is the best choice for lighting large areas of the premises. With interconnecting segments, a full-area lighting system can be installed that will require only 1 power cable.
When mounting the continuous line system, the profiles fit snugly against each other, leaving no gaps. Therefore, the final design of the luminaires looks unified, neat and monolithic.
Minija is the best choice for lighting large areas of the premises. With interconnecting segments, a full-area lighting system can be installed that will require only 1 power cable.
When mounting the continuous line system, the profiles fit snugly against each other, leaving no gaps. Therefore, the final design of the luminaires looks unified, neat and monolithic.
Just a three easy steps in combining quite a flexible solution. Imagine what could simple line look like by passing through the long corridors or wrapping your rooms.
Start segment
Integrated driver.
Through wiring inside to supply mains to other modules.
Endcap at the beginning.
Middle segment
Integrated driver.
Through wiring inside to supply mains to other modules.
No endcaps.
End segment
Integrated driver.
Endcap at the end.
Fixed output or dimmable (DALI, 0-10V, Casambi)
Fixed output or dimmable (DALI, 0-10V, Casambi)
